GL5-T/28A/155

Hết hàng
Thương hiệu: Pepperl+Fuchs Tình trạng: Hết hàng
General specifications
Light sourceIRED
Light typeInfrared, continuous light , 940 nm
Target size0.8 x 1.8 mm
Slot width5 mm
Slot depth8.5 mm
Ambient light limit1000 Lux
Functional safety related parameters
MTTF3760 a
Mission Time (TM)20 a
Diagnostic Coverage (DC)0%
Indicators/operating means
Function indicatorred LED lights up when receiving
the light beam
Electrical specifications
Operating voltage5 ... 24 V DC . class 2
No-load supply currentmax. 20 mA
Time delay before availability<2 ms
0₫
