DMSGS/DMSJ-020

Hết hàng
Thương hiệu: AIRTAC Tình trạng: Hết hàng
ModelNPN/PNP
Power supply voltage5V ~ 30V DC
Switching current30V/200mA Max.
Contact capacity6.0W Max.
Current consumption5mA Max.
Internal voltage drop0.7V Max.
Leakage current0.01mA Max.
Switching frequency1000Hz
Impact resistance50G
Circuit protectionReverse polarity protection Surge protection
Operating Temp.-10℃~70℃
EnclosureIP64/IP68
StandardCE marking, RoHS
0₫
